When you export your car model, the dialog that displays in SketchUp advising what's been exported to ASE should have in it entries similar to those at the left in this table. The column at the right indicates the purpose of each entry. |
|||
|
|
|
|
|
|
|
|
ASE Entries |
|
Reason For Entry |
|
|
|
|
|
|
|
|
|
camerafront camerarear carfront carrear nosecamera wheelfl wheelfr wheelrl wheelrr |
|
Car Effect Bones |
|
|
|
Peep01 Peep02 Peep03 Peep04 |
|
Peep Effects |
|
|
|
bone_RestraintOnePPivotPeep01 bone_RestraintOnePPivotPeep02 bone_RestraintOnePPivotPeep03 bone_RestraintOnePPivotPeep04 |
|
Parent Bones |
|
|
|
RestraintOnePPivotPeep01Opening RestraintOnePPivotPeep01OpenIdle RestraintOnePPivotPeep01Closing RestraintOnePPivotPeep01ClosedIdle RestraintOnePPivotPeep02Opening RestraintOnePPivotPeep02OpenIdle RestraintOnePPivotPeep02Closing RestraintOnePPivotPeep02ClosedIdle RestraintOnePPivotPeep03Opening RestraintOnePPivotPeep03OpenIdle RestraintOnePPivotPeep03Closing RestraintOnePPivotPeep03ClosedIdle RestraintOnePPivotPeep04Opening RestraintOnePPivotPeep04OpenIdle RestraintOnePPivotPeep04Closing RestraintOnePPivotPeep04ClosedIdle |
|
Parent Bone Set Points |
|
|
|
PivotPeep01 (15 faces) PivotPeep02 (15 faces) PivotPeep03 (15 faces) PivotPeep04 (15 faces) |
|
Parent Bone Meshes |
|
|
|
bone_RestraintTwoCRestraintPeep01 bone_RestraintTwoCRestraintPeep02 bone_RestraintTwoCRestraintPeep03 bone_RestraintTwoCRestraintPeep04 |
|
Child Bones |
|
|
|
RestraintTwoCRestraintPeep01Opening RestraintTwoCRestraintPeep01OpenIdle RestraintTwoCRestraintPeep01Closing RestraintTwoCRestraintPeep01ClosedIdle RestraintTwoCRestraintPeep02Opening RestraintTwoCRestraintPeep02OpenIdle RestraintTwoCRestraintPeep02Closing RestraintTwoCRestraintPeep02ClosedIdle RestraintTwoCRestraintPeep03Opening RestraintTwoCRestraintPeep03OpenIdle RestraintTwoCRestraintPeep03Closing RestraintTwoCRestraintPeep03ClosedIdle RestraintTwoCRestraintPeep04Opening RestraintTwoCRestraintPeep04OpenIdle RestraintTwoCRestraintPeep04Closing RestraintTwoCRestraintPeep04ClosedIdle |
|
Child Bone Set Points |
|
|
|
RestraintPeep01 (108 faces) RestraintPeep02 (108 faces) RestraintPeep03 (108 faces) RestraintPeep04 (108 faces) |
|
Child Bone Meshes |
|
|
|
Glass (44 faces) RCT3Swatch02 (28 faces) RCT3Swatch09 (4 faces) RCT3Swatch12 (874 faces) RCT3Swatch13 (190 faces) RCT3Swatch15 (74 faces) RCT3Swatch21 (4 faces) |
|
Car Textures For Polys Not Related To Pivots Or Restraints |
|
